Solar inverter - PRO 5.5KVA- OFF/Grid - SAKO

Solar inverter - PRO 5.5KVA- OFF/Grid - SAKO
Regular price $550.00
    • SAKO
    • Solar Charger Mode MPPT
    • Model Name: SUNON PRO 5.5KW
    • Capacity: 5.5Kw/5500W
    • Power Factor: 1.0
    • Operating Temp Range: -10~50C°
    • Inverter Mode
    • DC Input : 48VDC, 127A
    • AC Output: 230VAC- 50/60Hz - 23.9A
    • Rated Current : MPPT 100A
    • Rated Current : MPPT 100A
    • Rated Power: 6000W
    • Nominal Operating Volt : 240VDC
    • Max Solar Volt(VOC): 500VDC
    • MPPT Volt Range: 120~450VD
    • Other Mode
    • Transfer Time :10MS(UPS) 20MS(Appliances)
    •  Wave Form : Pure Shine Wave
    • AC charge current : 60/100A
    • It can work with or without battery
    • Auto restart while AC is recovering
    • Important note: directly guaranteed by Waked Electric Company, provided that the serial number is obtained

      • SAKO
      • Solar Charger Mode MPPT
      • Model Name: SUNON PRO 5.5KW
      • Capacity: 5.5Kw/5500W
      • Power Factor: 1.0
      • Operating Temp Range: -10~50C°
      • Inverter Mode
      • DC Input : 48VDC, 127A
      • AC Output: 230VAC- 50/60Hz - 23.9A
      • Rated Current : MPPT 100A
      • Rated Current : MPPT 100A
      • Rated Power: 6000W
      • Nominal Operating Volt : 240VDC
      • Max Solar Volt(VOC): 500VDC
      • MPPT Volt Range: 120~450VD
      • Other Mode
      • Transfer Time :10MS(UPS) 20MS(Appliances)
      •  Wave Form : Pure Shine Wave
      • AC charge current : 60/100A
      • It can work with or without battery
      • Auto restart while AC is recovering
      • Important note: directly guaranteed by Waked Electric Company, provided that the serial number is obtained
      • PV1800 VPM Series High Frequency Off Grid Solar Inverter (1KW)
      • Pure sine wave output
      • Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
      • Bult in MPPT 60A solar charge controller
      • Combining solar system, AC utility, and battery power source to supply continuous power
      • Overload, short circuit and Deep discharge protection
      • Cold start function
      • Support USB, RS485 monitoring function
      • WIFI remote monitoring (optional)
      • Compatible to generator



      MODEL PV18-1012 VPM
      Default Battery System Voltage 12VDC
      INVERTER OUTPUT
      Rated Power 1000VA / 1000W
      Surge Power 2000VA
      Waveform Pure sine wave
      AC Voltage Regulation (Batt.Mode) 220VAC~240VAC(Setting)
      Inverter Efficiency(Peak) 90%~93%
      Transfer Time 10ms(UPS / VDE4105) / 20ms(APL)
      AC INPUT
      Voltage 230VAC
      Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
      Frequency Range 50Hz / 60Hz (Auto sensing)
      BATTERY
      Normal voltage 12VDC
      Floating Charge Voltage 13.7VDC
      Overcharge Protection 15VDC
      SOLAR CHARGER & AC CHARGER
      Maximum PV Array Open Circuit Voltage 75VDC
      PV Array MPPT Voltage Range 15~75VDC
      Standby Power Consumption 2W
      Maximum PV Array Power 625W
      Maximum Solar Charge Current
      Maximum Efficiency 98%
      Maximum AC Charge Current 10A or 20A
      Maximum Charge Current 70A
      MECHANICAL SPECIFICATIONS
      Machine Dimensions (W*H*D)(mm) 225*355*92
      Package Dimensions (W*H*D)(mm) 410*300*78
      Net Weight(kg) 5
      Gross Weight(kg) 5.5
      OTHER
      Humidity 5% to 95% Relativ Humidity (Non-condensing)
      Operating Temperature 0°C~50°C
      Storage Temperature -15°C -60°C


    • SOLAR INVERTER - OFF GRID - 3KW - MUST
      translation missing: en.products.product.regular_price $475.00 $425.00 On Sale
    • MUST

      SOLAR INVERTER:

      Model Name: PV1800

      MD: PV18-3024 VHM

      Operating Temp.: -10c~50c

      Protection Class: Class 1

      Protection Degree: IP 20

      INVERTER Mode

      Rated Power: 3000VA/3000W

      DC INPUT: 24VDC, 130A

      AC OUTPUT: 230VAC 50Hz 13A

      Output Power Factor: 1.0

      AC Charger Mode:

      AC Input: 230VAC 50Hz 17.7A

      DC Output: 27VDC 30/20A

      SOLAR CHARGER Mode:

      Rated Current: 80A

      System Volt: 24VDC

      MPPT Volt Range: 30-130VDC

      Max Solar Volt(VOC): 145VDC

      Max Charge Current: 80A

    • Solar Inverter- On/OFF Grid -MUST 3 KW
      translation missing: en.products.product.regular_price $600.00 $580.00 On Sale
    • MPPT BASED SOLAR INVERTER - OFF GRID -  WELION BY MUST - 5.2K
      translation missing: en.products.product.regular_price $670.00 $650.00 On Sale
    • WELION BY MUST



      MPPT Solar Inverter

      MODEL Name: PV1800

      MD: PV18-5248 PRO

      Nominal Battery System Volt: 48VDC

      INVERTER OUTPUT

      Off-Grid Mode:



      Rated Power: 5200VA/5200W

      DC Input: 48VDC, 135A

      AC Output: 230VAC, 50Hz, 22.6A

      AC CHARGER MODE:

      AC Input: 230VAC, 50HZ, 45A

      DC Output: 48VDC, 60A (max)



      PV INPUT:

      Rated Power: 5000W



      Max. charger: 80A



      Norminal Operating Volt: 360VDC

      Max. Solar Volt(VOC): 450VDC

      MPPT Volt Range: 150~430VDC

      Max. PV Current: 18A



    • Solar Inverter- OFF Grid -MUST 10kw
      translation missing: en.products.product.regular_price $1,900.00
    • Solar Inverter - 3.5KVA - Off Grid - COVAX
      translation missing: en.products.product.regular_price $485.00 $450.00 On Sale
    • COVAX

      Hybrid Smart Solar Inverter

      • Model : CV-II-M-Plus 3.5KW
      • Operating Temp Range: 10~50°C
      • Inverter Mode
      • Rated Power ; 3500VA/3500W
      • DC Input : 24VDC, 162A
      • AC Output: 230VAC- 50/60Hz - 15.2A
      • AC Charger Mode
      • AC input: 230VAC - 50/60Hz-24.9A
      • DC Output :  27VDC
      • Max 80A. Default: 30A
      • AC Output ; 230VAC, 50/60Hz,15.2A
      • Solar Charger Mode
      • Rated Power : 5000W
      • Max Charger: 100A
      • Nominal Operating Volt: 240VDC
      • Max Solar Volt ; 500VDC
      • MPPT Volt Range 120~450VDC
