Solar
-
OREX
- *EXTRA BACKUP
- *EXTRA LIFE
- *LOW MAINTENANCE
- 12V 240A C10
- Model: OST-2400
- Voltage: 12
- Capacity: 240Ah @ C10 at 27c up to 1.80vpc (1.240+/-0.005 sp.gr*)
- Material: Polypropylene
- Battery: Deep cycle Tubular Flooded Advanced Lead Acid Battery
- Dimension: 20x37x49cm
- Weight: 70kg
OREX
- *EXTRA BACKUP
- *EXTRA LIFE
- *LOW MAINTENANCE
- 12V 200A C10
- Model: OST-2000
- Voltage: 12
- Capacity: 200Ah @ C10 at 27c up to 1.80vpc (1.240+/-0.005 sp.gr*)
- Material: Polypropylene
- Battery: Deep cycle Tubular Flooded Advanced Lead Acid Battery
- Dimension: 20x37x49cm
- Weight: 66kg
- WIFI FOR FELICITY INVERTER
- It can monitor the inverters’ operation status, And set up parameters of the inverters through your mobile phone
DEYE LB version
Hybrid Inverter ON/OFF GRID
SUN-6K-SG05LP-1EU
INCLUDING WIFI/PARALLEL KIT
Model |
SUN6-K-SG05LP-1EU |
Battery Input Data | |
Battery Type | Lead-acid or Li-Ion |
Battery Voltage Range (V) | 60~40 |
Max. Charging Current (A) | 135 |
Max. Discharging Current (A) | 135 |
External Temperature Sensor | Yes |
Charging Curve | 3 Stages / Equalization |
Charging Strategy for Li-Ion Battery | Self-adaption to BMS |
PV String Input Data | |
Max. DC Input Power (W) | 7800 |
Rated PV Input Voltage (V) | 500~125)370) |
Start-up Voltage (V) | 125 |
MPPT Voltage Range (V) | 425-150 |
Full Load DC Voltage Range (V) | 425-300 |
PV Input Current (A) | 13+13 |
Max. PV ISC (A) | 17+17 |
Number of MPPT/Strings per MPPT | 1+1/2 |
AC Output Data | |
Rated AC Output and UPS Power (W) | 6000 |
Max. AC Output Power (W) | 6600 |
AC Output Rated Current (A) | 27.3 |
Max. AC Current (A) | 30 |
Max. Continuous AC Passthrought (A) | 40 |
Peak Power (off grid) | 2 time of rated power, 10$ |
Power Factor | 0.8 leading to 0.8 lagging |
Output Frequency and Voltage | 60/50Hz; L/N/PE 230/220Vac (single phase) |
Grid Type | Single Phase |
DC Injection current (mA) | THD<%3 (Linear load<%1.50 |
Efficiency | |
Max. Efficiency | %97.60 |
Euro. Efficiency | %97.00 |
MPPT Efficiency | %99.90 |
Protection | |
Integrated | PV Input Lightning Protection, Anti-islanding Protection, PV String Input Reverse Polarity Protection, insulation Resistor Detection, Residual current monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection |
Output Over Voltage Protection | DC Type II / AC Type III |
Certifications and Standards | |
Grid Regulation | CEI 21-0, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98, VDE 1-1-0126, RD 1699, C11-10 |
Safety EMC/Standard | IEC/EN 4/3/2/1-6-61000, IEC/EN 1-62109, IEC/EN 2-62109 |
General Data | |
Operating Temperature Range | 60~45 , >45 derating |
Cooling | Natural cooling |
Noise (db) | <30db |
Communication with BMS | RS485; CAN |
Weight (kg) | 24 |
Size (mm) | 330W x 580H x 232D |
Protection Degree | IP65 |
Installation Style | Wall-mounted |
Warranty | 5 years |
SAKO
Pure Sine Wave
INCLUDING WIFIÂ Â Â Â Â Â Â &Â Â Â Â Â Â Â WITH PARALLEL
* RGB SCREEN*
- Model Name: SUNPOLO - 6KW
- Capacity: 6KVA-6000W
- Power Factor: 1.0
- Operating Temp. Range: 0~55c
- Inverter Mode:
- DC Input: 48VDC, 125A
- AC Output: 230VAC, 50/60Hz 26A
- MPPT Solar Charger Mode:
- Rated Power: 6000W
- Max. Solar Input Current: 27A
- Max PV Charge Current: 120A
- Nominal operating volt: 360VDC
- Max. Solar Volt(VOC): 500VDC
- SIZE: 535x425x224mm
- Weight: 15.0kg
Â
COVAX
Hybrid Smart Solar Inverter
- Model Name: CV-2400-24
- Operating Temp Range: -10~50°C
- Inverter ModeÂ
- Rated Power ; 2400VA/2400W
- DC Input : 24VDC, 100A
- AC Output: 230VAC- 50/60Hz - 10.4A
- AC Charger ModeÂ
- AC input: 230VAC - 50/60Hz-15.7A
- DC Output :Â 27VDC
- AC Output ; 230VAC, 50/60Hz,10.4A
- Max AC Charging Current: 60A
- Solar Charger ModeÂ
- Rated Power : 3000W
- Nominal Operating Volt: 240VDC
- Max Solar Volt(VOC) ; 450VDC
- MPPT Volt Range 90~430VDC
- Max Solar Charging Current: 80A
- Dimension: 10x26x43cm
COVAX
Hybrid Smart Solar Inverter
- Model : CV-ECO-1.5KW-12
- Operating Temp Range: 10~50°C
- Inverter ModeÂ
- Rated Power ; 1500VA/1500W
- DC Input : 12VDC, 125A
- AC Output: 230VAC- 50/60Hz - 6.5A
- AC Charger ModeÂ
- AC input: 230VAC - 50/60Hz-8.57A
- DC Output :Â 13.5VDC
- AC Output ; 230VAC, 50/60Hz,6.5A
- Max AC Charging Current: 60A
- Solar Charger ModeÂ
- Rated Power : 2000W
- Nominal Operating Volt: 240VDC
- Max Solar Volt(VOC) ; 450VDC
- MPPT Volt Range 90~430VDC
- Max Solar Charging Current: 80A
- Inverser Circuit Breaker
- 1 Pole
- 63A
- 400V
- AC: 22A
- 50/60Hz
- le; 63A/P(400V)=28KW
MODEL Name: MAX-8000
Operating Temp. Range: -10~50c
INVERTER Mode:
Rated Power: 8000VA/8000W
DC Input: 48VDC, 182.2A
AC Output: 230VAC 50/60Hz, 34.8A
AC Charger Mode:
AC Input: 230VAC 50/60Hz, 55.7A
DC Output: 54VDC
AC Output: 230VAC, 50/60Hz , 34.8A
Max. 80A, Default 30A
SOLAR CHARGER NODE:
Rated Power: 4000Wx2
Norminal Operating Volt: 240VDC
Max. Solar Volt(VOC); 500VDC
MPPT Volt. Range: 90~450VDC
Note :used only 3 month Like new
