Inverters
- COVAX
- Hybrid Smart Solar Inverter
- WITHOUT WIFI
-
- Inverter Charger:
- Model Name: CV-II-M-PLUS 6.2KW-48V
- Operating Temp Range: -10~50°C
- PV INPUT:
- Nominal Operating Volt: 360VDC
- Vmax: 500VDC
- PV Input Volt Range: 90~450VDC
- Imax PV: 27A
- Full load MPPT Range: 240~450VDC
- Rated Power ;6500W
- Max Solar Charging Current: 120A
- Grid/AC OUTPUT:
- Nominal OUTPUT Volt: 220/230/240VAC
- Feed-in Grid VOLT Range: 195~253VAC
- Feed-in Grid Freq.Range: 49~511+-Hz
- Nominal Output Current: 27.0A
- Power Factor Range:>0.99
- Max Conversion Efficiency(DC/AC):97%
- Nominal Operating Freq: 50/60Hz
- AC INPUT:
-
Nominal Operating Volt: 230VAC
- Max. input current: 40A
- Nominal Operating Freq: 50/60Hz
- Surge Power:12400VA
- Max AC Charging Current: 100A
- BATTERY:
-
Battery Volt Range: 40~63VDC
- Max Battery Current: 125A
- Dimension: 15x30x45cm
COVAX
- Hybrid Smart Solar Inverter
- Included WIFI
- MPPT SOLAR INVERTER
- Model Name: AXPERT MAX 8KW
- Operating Temp. Range: -10~50C
- Inverter ModeL:
- Rated Power: 8000VA/8000W
- DC Input: 48VDC, 182.2A
- AC Output: 230VAC, 50/60Hz, 34.8A
- AC Charger Mode:
-
AC Input: 230VAC, 50/60Hz, 60A
- DC Output: 54VDC
- Max.120A, Default 30A
- AC Output: 230VAC, 50/0Hz, 34.8A
- Solar Charger Mode:
- Rated Power: 4000Wx2
- Nominal Operating Volt: 240VDC
- Max. Solar Volt(VOC): 500VDC
- MPPT Volt Range:90~450VDC
- Enclosure: IP21
- Protective: Class1
STAR NEW
Voltronic
Hybrid Solar Inverter
Model Name: MPS-V II 3.5K
Operating Temp. Range: 10~50C
Inverter Mode:
Rated Power: 3500VA/3500W
DC Input: 24VDC, 162A
AC Output: 230VAC 50/60Hz, 15.2A
AC Charger Mode:
AC Input: 230VAC 50/60Hz, 24.9A
DC Output: 27VDC
Max. 80A, Default: 30A
AC Output: 230VAC, 50/60Hz, 15.2A
Solar Charger Mode:
Rated Power: 5000W
Max. Charger: 100A
Norminal Operating Volt: 240VDC
Max. Solar Volt (VOC): 500VDC
MPPT Volt Range: 120~450VDC
Ingress Protection: IP21
Protective Class: class I
Â
Â
Â
GROVOLT
MODEL Name: Rangar 8.2kw
Model Number :GI-R48-8.2KW
Operating Temp. Range:-10-50C
INVERTER ModeÂ
Rated Power:Â 8200VA/8200W
DC Input: 48VDC,188A
AC Output: 230VAC 50/60Hz 35.6A
AC Charger Mode:
Ac Input : 230VAC 50/60Hz 60A
Dc Output : 54VDC
Max 150A, Default 30A
AC Output : 230VAC 50/60Hz 35.6A
Solar Charger Mode:
Rated Power: 5000W x2
Nominal operating volt: 340VDCÂ
Max Solar volt (VOC) : 500VDC
MPPT Volt Range : 90~450VDC
Ingress protection : IP 21
Protective class : class 1
Â
BIG HOUSE
With Moving Screen
Works without batteries
Model Name: MPS-V II 5.5KW
- Operating Temp. Range: 10-50C
- Inverter Mode:
- Rated Power: 5500VA/5500W
-
DC Input: 48VDC, 127A
- AC Output: 230VAC 50/60Hz 23.9A
- AC Charger Mode:
- AC Input: 230VAC 50/60Hz 38.5A
- DC Output: 54VDC
- Max 80A, Default 30A
- AC Output: 230VAC 50/60Hz 23.9A
- Solar Charger Mode:
- Rated Power: 6000W
- Max Charger: 100A
- Norminal operating volt: 240VDC
- Max Solar Volt (VOC):l 500VDC
- MPPT Volt Range: 120-450VDC
- Ingress Protection: IP21
- Protective Class: class 1
- Size: 30x14x44cm
- GROWATT Brand
- Model Name: SPF 3500 ES
- Capacity: 3.5kva/3500w
- WITH FREE:Â
- Â Â Â Â WIFI DEVICE & PARALLEL KIT
- Solar Charger Mode:
- Max. PV input volt (VOC): 450VDC
- MPPT volt Range: 120~430VDC
- Number of input string: 1
- Max. PV input current: 18A
- Max. Charger current: 80A
- AC Charger Mode
- AC input: 230VAC 50/60Hz 29A
- Max. AC charger current: 80A
- Battery Mode
- Battery input 48VDC, 82A
- Type of battery: LEAD-ACIDE/LITHIUM
- Rated Power: 3500kva/3500w
- AC output: 230VAC, 50/60Hz, 16A
- Important note: directly guaranteed by Waked Electric Company, provided that the serial number is obtained
-
- Sako brand
- Model Name: PRO 3.5KVA- 100A-MPPT
- Capacity: 3.5KVA/3500W
- Power Factor: 1
- Operating Temp Range: -10~50C°
- Inverter Mode
- DC Input : 24VDC, 162A
- AC Output: 230VAC- 50/60Hz - 15.2A
- Solar Charger Mode MPPT & AC Charger
- Rated Power: 5000W
- Nominal Operating Volt : 24VDC
- Min Solar Volt: 500VDC
- MPPT Volt Range: 120~450VDC
- Other Mode
- Transfer Time :10MS(UPS) 20MS(Appliances)
- Â Wave Form : Pure Shine Wave
- AC charge current : 60/100A
- It can work with or without battery
- Auto restart while AC is recovering
- Important note: directly guaranteed by Waked Electric Company, provided that the serial number is obtained
- SAKO
- Solar Charger Mode MPPT
- Model Name: SUNON PRO 5.5KW
- Capacity: 5.5Kw/5500W
- Power Factor: 1.0
- Operating Temp Range: -10~50C°
- Inverter Mode
- DC Input : 48VDC, 127A
- AC Output: 230VAC- 50/60Hz - 23.9A
- Rated Current : MPPT 100A
- Rated Current : MPPT 100A
- Rated Power: 6000W
- Nominal Operating Volt : 240VDC
- Max Solar Volt(VOC): 500VDC
- MPPT Volt Range: 120~450VD
- Other Mode
- Transfer Time :10MS(UPS) 20MS(Appliances)
- Â Wave Form : Pure Shine Wave
- AC charge current : 60/100A
- It can work with or without battery
- Auto restart while AC is recovering
- Important note: directly guaranteed by Waked Electric Company, provided that the serial number is obtained
100A MPPT & Parrallel-able workable w/o battery
Model |
 SUNPAX 505KW |
The rated power | Â 5500VA/5500W |
 INPUT                                       |
Voltage | Â 230 VAC |
Selectable Voltage Range | 170-280VAC(UPS),90-280VAC(Appliances) |
Frequency Range | 50Hz/60Hz(Auto sensing) |
OUTPUTÂ Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â |
AC Voltage Regulation (Batt.Model) | Â 230VAC+-5% |
Surge Power | 11000VA |
Efficiency(Peak) | >90% |
Transfer Time | 10MS(UPS).20MS(Appliances) |
Wave form | Pure sine wave |
No load current | 1.3A |
 BATTERY                            |
Battery Voltage | Â 48VDC |
Low battery alarming voltage | 44.0VDC |
Low battery cut off protection voltage | 42VDC |
Low battery recovery voltage | 46.0VDC |
floating charge voltage | 54VDC |
Overcharge protection | 64VDC |
 MPPT SOLAR CHARGER & AC CHARGER   |
Maximum PV Array power | Â 5500W |
MPPT range at operation Vol. | 120-450VDC |
Maximum PV array open circuit Vol. | 500VDC |
Number of MPPT trackers / Max output current | 100A |
Maximum AC Charge current | 80A |
Maximum charge current | 100A |
 BEST PANEL CONFIGUTATION     |
Best panel configuration | Â 300Wp*9pcs*30V(2700Wp)*2Parallel |
 PHYSICAL           |
Products Dimension .D*W*H(mm) | Â 498mm*313mm*123mm |
Packing size D*W*H(mm) | 577mm*395mm*217mm |
Net weight (kgs) | 10.0KG |
G.w. kg | 11.3KG |
 OPERATING ENVIRONMENT     |
Humidity | Â 5% to 95% Relative Humidity (Non-condensing) |
Operation temperature | 0C.50C |
SAKO
Pure Sine Wave
INCLUDING WIFIÂ Â Â Â Â Â Â &Â Â Â Â Â Â Â WITH PARALLEL
* RGB SCREEN*
- Model Name: SUNPOLO - 6KW
- Capacity: 6KVA-6000W
- Power Factor: 1.0
- Operating Temp. Range: 0~55c
- Inverter Mode:
- DC Input: 48VDC, 125A
- AC Output: 230VAC, 50/60Hz 26A
- MPPT Solar Charger Mode:
- Rated Power: 6000W
- Max. Solar Input Current: 27A
- Max PV Charge Current: 120A
- Nominal operating volt: 360VDC
- Max. Solar Volt(VOC): 500VDC
- SIZE: 535x425x224mm
- Weight: 15.0kg
Â
- AUSTA by DEYE original
- (One of Top Ten Brands Over The World) Including WIFI/Parallel Kit Hybrid Inverter on/Off Grid
- Warranty: 5Yrs Model Name: AU1--P5K1G-LE-EU Product Type: Hybrid Inverter Enclosure: IP65 Ambient Temp:-25-60C°(>45C° De-rating) Charge Mode
- Battery Volt: 48VDC(40-60V)
- Battery Current: 120ADCMax
- Ac Input Volt: 230VAC
- AC Input Freq:50/60Hz
- AC Input Rated Current: 21.7AC
- Max AC Input Current: 25AC Max
- Max AC Input Power: 5500W
- PV input Volt: 370VDC(100VDC-500VDC)
- MPPT Input Range: 120VDC-425VDC
- PV Input Current: 13ADC+13ADC
- Max PV Input Power: 6500W
- Max PV ISC: 16.5ADC+16.5ADC
- AC Output Volt: 230VAC
- Ac Output Freq: 50/60Hz
- AC Output Rated Current: 21.7AC
- Max AC Output Current: 25AC Max
- Max AC Output Power: 5500W
- AC Output Rated Power: 5500W
- AC Output Power Factor: 0.8 Leading to 0.8 Lagging
- Max AC ISC: 75AC
- Battery Discharge Volt: 40V-60VDC
- Battery Discharge Current: 120ADC Max
- Battery Discharge Power: 5500W
- AC Output Volt: 230VAC
- AC Output Freq: 50/60Hz
- AC Output Rated Current: 21.7AC
- AC Output Rated Power: 5000W
- Max. Continuous AC Pass Through: 35AC
- Peak Output Power: 10000W 10sec
- Battery Discharge Volt: 40V-60VDC
- Max Discharge Current: 120ADC Max
- 5 year warranty
